Guide by Xiden and SEGARPGFAN
Special Thanks to hawkzer0, itsthinkingstill
1. Hardware Required
The hardware needed should be easy to find on Ebay or Amazon.
1. UNLOCKED Cisco / Linksys SPA1001 FXS VoIP Phone Adapter (Try to find one that comes with a power adapter) - Other VOIP adapters may work but they have not been tested yet. As more are tested in the future I'll continue to add to a list of confirmed working VOIP adapters
2. Sega Saturn NetLink
3. Phone Cord
4. Ethernet Cable
2. Hardware Setup
1. Plug in your Ethernet cable from your router to the VOIP Adapter
2. Plug one end of your telephone cord to the VOIP adapter and the other end to LINE on the Sega Saturn NetLink
3. VOIP Configuration - This Guide assumes you have a Linksys SPA1001 FXS VOIP Phone Adapter
1. You first need to login to your router and find out what IP Address your voip adapter was assigned.
2. In my case it was assigned 192.168.1.80, The device should also already be named "SipuraSPA" as seen in the screen shot below
3. Type in that ip address into any browser and press enter then you'lll need to click on "Admin Login" and then "Advanced" on the top right hand corner of your screen
4. Click on System Tab
Set DHCP to NO,
Setup a static IP of your choosing
Enter your routers Gateway (Find this by using ipconfig on windows command prompt)
NetMask must be 255.255.255.0
5. Click on the SIP Tab and Verify/Match your settings to the image below
6. Click on Provisioning and Verify/Match your settings to the image below
7. Click on Phone and Verify/Match your settings to the image below
8. Click on Line 1 and Verify/Match your settings to the image below
If you are unable to get past the Dialing stage on netlink then your IP could be blocking port 5060. In this case you'll need to change the SIP Port and EXT SIP Port to 4000
9. Log back into your router. YOU MUST EITHER DMZ YOUR VOIP ADAPTERS IP ADDRESS OR PORT FORWARD 5060 UDP and 16384 - 16482 UDP IF YOU CHANGE YOUR VOIPS PORT NUMBER THEN YOU NEED TO PORT FORWARD THAT NUMBER INSTEAD!
4. Saturn Setup
1. Put in any NetLink compatible game into your Saturn.
2. When the game loads select "QuickLink"
3. Click on "Setup" on the main menu and you'll be brought to the following screen
4. Click on "Character" select an Avatar
5. Click on "Code Name" Type desired username
6. (Optional) Click "Taunt" to put in some trash talk you want to show up before the match starts
7. Click on "Phone Setup" select Tone
8. Click Return
4a. HOSTING A NETLINK GAME
1. Simply click on "Wait" , then you'll need to text message your opponent that you are ready for them to dial you. Thats it! You'll also have the option to practice while you wait for them to dial but I just hit no to make the connection processes faster.
4b. DIALING INTO A NETLINK GAME
1. You will need your opponents Public IP Address. If they followed this guide then their UserID will be 11 and port will be 5060. However these may very depending on what user SIP Port was entered.
to Dial you'll need to enter it in the following format
Example: If you both have followed this guide both your UserID's will be 11 and ports will be 5060. We'll assume the person you are dialing's public IP is 127.1.1.0
So you would enter 11*127*1*1*0*5060#
Note that you may need to try port 4000 in the event neither person can get past the "Dialing" screen *See Section 3.7 on Configuring Line 1*
2. Dont hit "Dial" until your opponent is in "Wait" mode first. Once they text you they are in wait mode then simply hit dial.
3. Enjoy the game!
Test if your Internet Connection can handle VOIP - http://www.whichvoip.com/voip/speed_test/ppspeed.html
More tips Coming Soon!
