Gens4All with Z80 Emulation

[Ian Micheal]

Don't feel afraid to reach out
Could have saved you an hour
https://github.com/mrneo240/openmenu/bl ... font_bmf.c

I hope to see sneak peeks or such on the game! Great to see you aren't leaving but rather refocusing into a single thing.

The timestamps on my backups for my BMFont code start in 2017. I guess I could've saved you an hour if I posted it.

I think I'm going to make a thread to post about progress. Having people interested should help motivate me.

Problem only happens on rca leads like i said... It works perfect on vga since i dont use rca leads it's not a problem for me but users..
the emulator does not crash and you can go back to the menu there is no sound ether on rca leads when this happens, other games works fine just a few that do this.. The problem game as i said this happens on few others..

Huh. I guess the issue is probably with the emulator core, then. I have no idea how the cable type could cause that. If I manage to get my setup changed so that I can test on NTSC easier, I might go back and take a look at it.

debug loading the rom now

```

Code: Select all

OUTPUT:> Loading rom Phantasy Star GenIIII - Working Designs (v6.1).bin... At PC: 8C096366, PR: 8C096366
OUTPUT:> Z80 Clock 0
OUTPUT:> R0: 8C001AC0  R1: 00000010  R2: 00000000  R3: 8C0029C6
OUTPUT:> R4: 00000000  R5: 00000000  R6: 00000000  R7: 00000798
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 0000013A  R11: 8C0AB168
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 00277214  R15: 8CFE66B8
OUTPUT:> At PC: 8C096366, PR: 8C096366
OUTPUT:> kernel panic: Watchdog timeout
OUTPUT:> arch: aborting the system
STATE:> Upload processus completed on 1/12/2022 - 20:35:08, Exit Code : 0

```

Code: Select all

OUTPUT:> KallistiOS Git revision v2.0.0-489-gfae2358-dirty:
OUTPUT:>   Sun 26 Sep 2021 11:00:31 PM CDT
OUTPUT:>   alex@alex-ThinkPad-P15-Gen-1:/opt/toolchains/dc/kos
OUTPUT:> maple: active drivers:
OUTPUT:>     Dreameye (Camera): Camera
OUTPUT:>     Sound Input Peripheral: Microphone
OUTPUT:>     PuruPuru (Vibration) Pack: JumpPack
OUTPUT:>     VMU Driver: Clock, LCD, MemoryCard
OUTPUT:>     Mouse Driver: Mouse
OUTPUT:>     Keyboard Driver: Keyboard
OUTPUT:>     Controller Driver: Controller
OUTPUT:>     Lightgun: LightGun
OUTPUT:>   DMA Buffer at ac5f1120
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> fs_romdisk: mounting image at 0x8c0cff6c at /rd
OUTPUT:> dc-load console support enabled
OUTPUT:> maple: attached devices:
OUTPUT:>   A0: Dreamcast Controller          (01000000: Controller)
OUTPUT:> MAIN !!!!
OUTPUT:> Init genesis bios
OUTPUT:> InitFont
OUTPUT:> Reset variables
OUTPUT:> Init CPUs
OUTPUT:> Load config
OUTPUT:> Load_Config './/gens.cfg'
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Main loop
OUTPUT:> Sound Rate   : 22050
OUTPUT:> Sound Enabled: 1
OUTPUT:> DAC Enabled  : 1
OUTPUT:> Z80 State    : 1
OUTPUT:> CCR: 00000105
OUTPUT:> RD: 64
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 3420
OUTPUT:> Texmode: 2
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 252
OUTPUT:> fs_iso9660: disc change detected
OUTPUT:>   (joliet level 3 extensions detected)
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Loading rom Phantasy Star GenIIII - Working Designs (v6.1).bin... At PC: 8C096366, PR: 8C096366
OUTPUT:> Z80 Clock 0
OUTPUT:> R0: 8C001AC0  R1: 00000010  R2: 00000000  R3: 8C0029C6
OUTPUT:> R4: 00000000  R5: 00000000  R6: 00000000  R7: 00000798
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 0000013A  R11: 8C0AB168
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 00277214  R15: 8CFE66B8
OUTPUT:> At PC: 8C096366, PR: 8C096366
OUTPUT:> kernel panic: Watchdog timeout
OUTPUT:> arch: aborting the system
STATE:> Upload processus completed on 1/12/2022 - 20:35:08, Exit Code : 0

now this is what happens yet it worked the other day and i made a video on hardware never had this type of thing before where it worked now it does this every time

[TapamN]

Code: Select all

OUTPUT:> KallistiOS Git revision v2.0.0-489-gfae2358-dirty:
OUTPUT:>   Sun 26 Sep 2021 11:00:31 PM CDT
OUTPUT:>   alex@alex-ThinkPad-P15-Gen-1:/opt/toolchains/dc/kos
OUTPUT:> maple: active drivers:
OUTPUT:>     Dreameye (Camera): Camera
OUTPUT:>     Sound Input Peripheral: Microphone
OUTPUT:>     PuruPuru (Vibration) Pack: JumpPack
OUTPUT:>     VMU Driver: Clock, LCD, MemoryCard
OUTPUT:>     Mouse Driver: Mouse
OUTPUT:>     Keyboard Driver: Keyboard
OUTPUT:>     Controller Driver: Controller
OUTPUT:>     Lightgun: LightGun
OUTPUT:>   DMA Buffer at ac5f1120
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> fs_romdisk: mounting image at 0x8c0cff6c at /rd
OUTPUT:> dc-load console support enabled
OUTPUT:> maple: attached devices:
OUTPUT:>   A0: Dreamcast Controller          (01000000: Controller)
OUTPUT:> MAIN !!!!
OUTPUT:> Init genesis bios
OUTPUT:> InitFont
OUTPUT:> Reset variables
OUTPUT:> Init CPUs
OUTPUT:> Load config
OUTPUT:> Load_Config './/gens.cfg'
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Main loop
OUTPUT:> Sound Rate   : 22050
OUTPUT:> Sound Enabled: 1
OUTPUT:> DAC Enabled  : 1
OUTPUT:> Z80 State    : 1
OUTPUT:> CCR: 00000105
OUTPUT:> RD: 64
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 3420
OUTPUT:> Texmode: 2
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 252
OUTPUT:> fs_iso9660: disc change detected
OUTPUT:>   (joliet level 3 extensions detected)
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Loading rom Phantasy Star GenIIII - Working Designs (v6.1).bin... At PC: 8C096366, PR: 8C096366
OUTPUT:> Z80 Clock 0
OUTPUT:> R0: 8C001AC0  R1: 00000010  R2: 00000000  R3: 8C0029C6
OUTPUT:> R4: 00000000  R5: 00000000  R6: 00000000  R7: 00000798
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 0000013A  R11: 8C0AB168
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 00277214  R15: 8CFE66B8
OUTPUT:> At PC: 8C096366, PR: 8C096366
OUTPUT:> kernel panic: Watchdog timeout
OUTPUT:> arch: aborting the system
STATE:> Upload processus completed on 1/12/2022 - 20:35:08, Exit Code : 0

now this is what happens yet it worked the other day and i made a video on hardware never had this type of thing before where it worked now it does this every time

It looks like the watchdog is timing out while loading the ROM? I thought I paused the watchdog while loading?

Er, I can't find the pause call, so I guess not? I'm surprised people could load larger ROMs at all from disc.

Here's a quick version 4.2, which pauses the watchdog when loading ROMs. I didn't include the full source, just the single file modified file compared to version 4.1.

[Ian Micheal]

Code: Select all

OUTPUT:> KallistiOS Git revision v2.0.0-489-gfae2358-dirty:
OUTPUT:>   Sun 26 Sep 2021 11:00:31 PM CDT
OUTPUT:>   alex@alex-ThinkPad-P15-Gen-1:/opt/toolchains/dc/kos
OUTPUT:> maple: active drivers:
OUTPUT:>     Dreameye (Camera): Camera
OUTPUT:>     Sound Input Peripheral: Microphone
OUTPUT:>     PuruPuru (Vibration) Pack: JumpPack
OUTPUT:>     VMU Driver: Clock, LCD, MemoryCard
OUTPUT:>     Mouse Driver: Mouse
OUTPUT:>     Keyboard Driver: Keyboard
OUTPUT:>     Controller Driver: Controller
OUTPUT:>     Lightgun: LightGun
OUTPUT:>   DMA Buffer at ac5f1120
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> fs_romdisk: mounting image at 0x8c0cff6c at /rd
OUTPUT:> dc-load console support enabled
OUTPUT:> maple: attached devices:
OUTPUT:>   A0: Dreamcast Controller          (01000000: Controller)
OUTPUT:> MAIN !!!!
OUTPUT:> Init genesis bios
OUTPUT:> InitFont
OUTPUT:> Reset variables
OUTPUT:> Init CPUs
OUTPUT:> Load config
OUTPUT:> Load_Config './/gens.cfg'
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Main loop
OUTPUT:> Sound Rate   : 22050
OUTPUT:> Sound Enabled: 1
OUTPUT:> DAC Enabled  : 1
OUTPUT:> Z80 State    : 1
OUTPUT:> CCR: 00000105
OUTPUT:> RD: 64
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 3420
OUTPUT:> Texmode: 2
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 252
OUTPUT:> fs_iso9660: disc change detected
OUTPUT:>   (joliet level 3 extensions detected)
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Loading rom Phantasy Star GenIIII - Working Designs (v6.1).bin... At PC: 8C096366, PR: 8C096366
OUTPUT:> Z80 Clock 0
OUTPUT:> R0: 8C001AC0  R1: 00000010  R2: 00000000  R3: 8C0029C6
OUTPUT:> R4: 00000000  R5: 00000000  R6: 00000000  R7: 00000798
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 0000013A  R11: 8C0AB168
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 00277214  R15: 8CFE66B8
OUTPUT:> At PC: 8C096366, PR: 8C096366
OUTPUT:> kernel panic: Watchdog timeout
OUTPUT:> arch: aborting the system
STATE:> Upload processus completed on 1/12/2022 - 20:35:08, Exit Code : 0

now this is what happens yet it worked the other day and i made a video on hardware never had this type of thing before where it worked now it does this every time

It looks like the watchdog is timing out while loading the ROM? I thought I paused the watchdog while loading?

Er, I can't find the pause call, so I guess not? I'm surprised people could load larger ROMs at all from disc.

Here's a quick version 4.2, which pauses the watchdog when loading ROMs. I didn't include the full source, just the single file modified file compared to version 4.1.

Well that explains it how one time i got lucky and it just worked thank you TapanM

[Ian Micheal]

Code: Select all

OUTPUT:> KallistiOS Git revision v2.0.0-489-gfae2358-dirty:
OUTPUT:>   Sun 26 Sep 2021 11:00:31 PM CDT
OUTPUT:>   alex@alex-ThinkPad-P15-Gen-1:/opt/toolchains/dc/kos
OUTPUT:> maple: active drivers:
OUTPUT:>     Dreameye (Camera): Camera
OUTPUT:>     Sound Input Peripheral: Microphone
OUTPUT:>     PuruPuru (Vibration) Pack: JumpPack
OUTPUT:>     VMU Driver: Clock, LCD, MemoryCard
OUTPUT:>     Mouse Driver: Mouse
OUTPUT:>     Keyboard Driver: Keyboard
OUTPUT:>     Controller Driver: Controller
OUTPUT:>     Lightgun: LightGun
OUTPUT:>   DMA Buffer at ac5f1120
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> fs_romdisk: mounting image at 0x8c0cff6c at /rd
OUTPUT:> dc-load console support enabled
OUTPUT:> maple: attached devices:
OUTPUT:>   A0: Dreamcast Controller          (01000000: Controller)
OUTPUT:> MAIN !!!!
OUTPUT:> Init genesis bios
OUTPUT:> InitFont
OUTPUT:> Reset variables
OUTPUT:> Init CPUs
OUTPUT:> Load config
OUTPUT:> Load_Config './/gens.cfg'
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Main loop
OUTPUT:> Sound Rate   : 22050
OUTPUT:> Sound Enabled: 1
OUTPUT:> DAC Enabled  : 1
OUTPUT:> Z80 State    : 1
OUTPUT:> CCR: 00000105
OUTPUT:> RD: 64
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 3420
OUTPUT:> Texmode: 2
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 252
OUTPUT:> fs_iso9660: disc change detected
OUTPUT:>   (joliet level 3 extensions detected)
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Loading rom Phantasy Star GenIIII - Working Designs (v6.1).bin... At PC: 8C096366, PR: 8C096366
OUTPUT:> Z80 Clock 0
OUTPUT:> R0: 8C001AC0  R1: 00000010  R2: 00000000  R3: 8C0029C6
OUTPUT:> R4: 00000000  R5: 00000000  R6: 00000000  R7: 00000798
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 0000013A  R11: 8C0AB168
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 00277214  R15: 8CFE66B8
OUTPUT:> At PC: 8C096366, PR: 8C096366
OUTPUT:> kernel panic: Watchdog timeout
OUTPUT:> arch: aborting the system



STATE:> Upload processus completed on 1/12/2022 - 20:35:08, Exit Code : 0

now this is what happens yet it worked the other day and i made a video on hardware never had this type of thing before where it worked now it does this every time

It looks like the watchdog is timing out while loading the ROM? I thought I paused the watchdog while loading?

Er, I can't find the pause call, so I guess not? I'm surprised people could load larger ROMs at all from disc.

Here's a quick version 4.2, which pauses the watchdog when loading ROMs. I didn't include the full source, just the single file modified file compared to version 4.1.

Code: Select all

New version
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Loading rom Phantasy Star GenIIII - Working Designs (v6.1).bin... At PC: 8C096386, PR: 8C096386
OUTPUT:> Z80 Clock 59738
OUTPUT:> R0: 000000A0  R1: 00004A58  R2: A05F7000  R3: 00000378
OUTPUT:> R4: 8C5FFA04  R5: 00000000  R6: 00000094  R7: 00000798
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 000002B4  R11: 8C0AB188
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 00279A14  R15: 8CFE66B8
OUTPUT:> At PC: 8C096386, PR: 8C096386
OUTPUT:> Z80 Clock 59738
OUTPUT:> R0: 8C001A7C  R1: 00000010  R2: 0000000B  R3: 00000003
OUTPUT:> R4: 00000000  R5: 00000000  R6: 00000000  R7: 00000798
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 0000066C  R11: 8C0AB188
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 0009DA14  R15: 8CFE66B8
OUTPUT:> kernel panic: Watchdog timeout
OUTPUT:> arch: aborting the system
STATE:> Upload processus completed on 1/13/2022 - 12:48:45, Exit Code : 0

Seems the same problem but it did almost work

[Ian Micheal]

works from loading from serial btw

Code: Select all

OUTPUT:> KallistiOS Git revision v2.0.0-489-gfae2358-dirty:
OUTPUT:>   Sun 26 Sep 2021 11:00:31 PM CDT
OUTPUT:>   alex@alex-ThinkPad-P15-Gen-1:/opt/toolchains/dc/kos
OUTPUT:> maple: active drivers:
OUTPUT:>     Dreameye (Camera): Camera
OUTPUT:>     Sound Input Peripheral: Microphone
OUTPUT:>     PuruPuru (Vibration) Pack: JumpPack
OUTPUT:>     VMU Driver: Clock, LCD, MemoryCard
OUTPUT:>     Mouse Driver: Mouse
OUTPUT:>     Keyboard Driver: Keyboard
OUTPUT:>     Controller Driver: Controller
OUTPUT:>     Lightgun: LightGun
OUTPUT:>   DMA Buffer at ac5f1140
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> fs_romdisk: mounting image at 0x8c0cff8c at /rd
OUTPUT:> dc-load console support enabled
OUTPUT:> maple: attached devices:
OUTPUT:>   A0: Dreamcast Controller          (01000000: Controller)
OUTPUT:> MAIN !!!!
OUTPUT:> Init genesis bios
OUTPUT:> InitFont
OUTPUT:> Reset variables
OUTPUT:> Init CPUs
OUTPUT:> Load config
OUTPUT:> Load_Config './/gens.cfg'
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Main loop
OUTPUT:> Sound Rate   : 22050
OUTPUT:> Sound Enabled: 1
OUTPUT:> DAC Enabled  : 1
OUTPUT:> Z80 State    : 1
OUTPUT:> CCR: 00000105
OUTPUT:> RD: 64
OUTPUT:> vid_set_mode: 640x480 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 3420
OUTPUT:> Texmode: 2
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 252
OUTPUT:> fs_iso9660: disc change detected
OUTPUT:>   (joliet level 3 extensions detected)
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Loading rom Phantasy Star GenIIII.bin... done.
OUTPUT:> ***LOADING SRAM***
OUTPUT:> /ram/GENS4ALL_QhD
OUTPUT:> Init_Genesis: Sound_Enable is 1
OUTPUT:> Initing_Sound
OUTPUT:> Sound Rate: 22050
OUTPUT:> Audiobuf size: 32768
OUTPUT:> Name : "PHANTASY STAR The end of the millennium "
OUTPUT:> NameW: "PHANTASY STAR The end of the millennium "
OUTPUT:> Version: " MK-1307 -00"
OUTPUT:> Sonic Z80: 0
OUTPUT:> Sonic 2: 0
OUTPUT:> Ristar: 0
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 3420

No problem with the core loading the game it's just from a cdr

[TapamN]

It seems like it's still getting stuck in cdrom_exec_cmd somehow. Alright, here's a version with the watchdog disabled. It will probably end up just freezing.

[Ian Micheal]

It seems like it's still getting stuck in cdrom_exec_cmd somehow. Alright, here's a version with the watchdog disabled. It will probably end up just freezing.

New version still did this but again works from loading the rom f/pc with a coders cable ?

Code: Select all

OUTPUT:> Texmode: 2
OUTPUT:> Texmode: 2
OUTPUT:> chars size: 252
OUTPUT:> fs_iso9660: disc change detected
OUTPUT:>   (joliet level 3 extensions detected)
OUTPUT:> vid_set_mode: 320x240 VGA
OUTPUT:> pvr: disabling vertical scaling for VGA
OUTPUT:> Loading rom Phantasy Star GenIIII - Working Designs (v6.1).bin... At PC: 8C0963A6, PR: 8C0963A6
OUTPUT:> Z80 Clock 0
OUTPUT:> R0: 8C001000  R1: FFFFB9E5  R2: A05F7080  R3: 000002D8
OUTPUT:> R4: 00000000  R5: 00000000  R6: 00000000  R7: 00000002
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 0000012D  R11: 8C0AB1A8
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 0027DA14  R15: 8CFE66B8
OUTPUT:> At PC: 8C0963A6, PR: 8C0963A6
OUTPUT:> Z80 Clock 0
OUTPUT:> R0: 8C001A98  R1: 00000013  R2: 00000010  R3: 00000001
OUTPUT:> R4: 000004F8  R5: FFFFF904  R6: 00000000  R7: 00000798
OUTPUT:> R8: 00000001  R9: 8C0000BC  R10: 000004D8  R11: 8C0AB1A8
OUTPUT:> R12: 000007FF  R13: 00000800  R14: 000A8214  R15: 8CFE66B8
OUTPUT:> kernel panic: Watchdog timeout
OUTPUT:> arch: aborting the system
STATE:> Upload processus completed on 1/13/2022 - 16:46:57, Exit Code : 0

Still saying this OUTPUT:> kernel panic: Watchdog timeout for a cdr but works on GDEMU with out trouble ? Seek time? works on dreamshell as well.. Just not a cdr

[TapamN]

Yeah, it occurred to me a couple minutes ago, even before I read your post, that I disabled it incorrectly. Here's attempt two. I even tested and infinite loop this time.

Actually, it looks like my attempt to disable it only during loads didn't work because I made the same mistake?

[Ian Micheal]

Yeah, it occurred to me a couple minutes ago, even before I read your post, that I disabled it incorrectly. Here's attempt two. I even tested and infinite loop this time.

Actually, it looks like my attempt to disable it only during loads didn't work because I made the same mistake?

fixed now working loading from a cdr with this version well done

[MoeFoh]

Yeah, it occurred to me a couple minutes ago, even before I read your post, that I disabled it incorrectly. Here's attempt two. I even tested and infinite loop this time.

Actually, it looks like my attempt to disable it only during loads didn't work because I made the same mistake?

fixed now working loading from a cdr with this version well done

I'll make a CDR version with this new binary w/ padding shortly. I'm also going to chop extra "_"'s off the filenames.

Get it here:
https://www.dreamcast-talk.com/forum/vi ... 51&t=14933
